Propulsion

Internal combustion engines, electric motors, and controllers

Propulsion systems in powertrains include internal combustion spark-ignition (SI) engines, compression-ignition (CI) engines, and electric motors. Use the propulsion blocks to assemble engine subsystems and controllers for hardware-in-the-loop (HIL) engine control design, vehicle-level fuel economy, and performance simulations.

Blocks

expand all

Engines and Controllers

Mapped CI EngineCompression-ignition engine model using lookup tables
Mapped SI EngineSpark-ignition engine model using lookup tables
CI ControllerCompression-ignition controller that includes air mass flow, torque, and EGR estimation
SI ControllerSpark-ignition engine controller that uses the driver torque request

Components

CI Core EngineCompression-ignition engine from intake to exhaust port
SI Core EngineSpark-ignition engine from intake to exhaust port
Mapped Core EngineSteady-state core engine model using lookup tables
Boost Drive ShaftBoost drive shaft speed
CompressorCompressor for boosted engines
Control Volume SystemConstant volume open thermodynamic system with heat transfer
Flow BoundaryFlow boundary for ambient temperature and pressure
Flow RestrictionIsentropic ideal gas flow through an orifice
Heat ExchangerIntercooler or exhaust gas recirculation (EGR) cooler
TurbineTurbine for boosted engines

Motors and Inverters

Flux-Based PMSMFlux-based permanent magnet synchronous motor
Induction MotorThree-phase induction motor
Interior PMSM Three-phase interior permanent magnet synchronous motor with sinusoidal back electromotive force
Mapped MotorMapped motor and drive electronics operating in torque-control mode
Surface Mount PMSMThree-phase exterior permanent magnet synchronous motor with sinusoidal back electromotive force
Three-Phase Voltage Source InverterThree-phase voltage source inverter

Controllers

Equivalent Consumption Minimization StrategyEnergy management controller for P0–P4 hybrid electric vehicles
Flux-Based PM ControllerController for a flux-based permanent magnet synchronous motor
IM ControllerInternal torque-based, field-oriented controller for an induction motor with an optional outer-loop speed controller
Interior PM ControllerTorque-based, field-oriented controller for an internal permanent magnet synchronous motor
Surface Mount PM ControllerTorque-based, field-oriented controller for a surface mount permanent magnet synchronous motor

Topics

Internal Combustion Engines

SI Core Engine Air Mass Flow and Torque Production

The SI engine air mass flow calculation uses either a speed-density or a dual-independent cam phaser model. To calculate the brake torque, the SI engine uses either a simple torque or a structured torque model.

CI Core Engine Air Mass Flow and Torque Production

The CI engine air mass flow calculation uses a speed-density model. To calculate the brake torque, you can configure the CI engine to use a simple torque or a structured torque model.

Electric Motors

Generate Parameters for Flux-Based Blocks

Generate optimized current controller and flux parameters for the Flux-Based PM Controller and Flux-Based PMSM blocks.

Related Information

Featured Examples

Conventional Vehicle Reference Application

Conventional Vehicle Reference Application

Simulate a full vehicle model with an internal combustion engine, transmission, and associated powertrain control algorithms. Use for powertrain matching analysis and component selection, control and diagnostic algorithm design, and hardware-in-the-loop (HIL) testing.

Open Example
CI Engine Dynamometer Reference Application

CI Engine Dynamometer Reference Application

Simulate a CI engine plant and controller connected to a dynamometer with a tailpipe emission analyzer. Use to calibrate, validate, and optimize the CI engine controller and plant model parameters before integrating the engine with the vehicle model.

Open Example
SI Engine Dynamometer Reference Application

SI Engine Dynamometer Reference Application

Simulate a SI engine plant and controller connected to a dynamometer with a tailpipe emission analyzer. Use to calibrate, validate, and optimize the SI engine controller and plant model parameters before integrating the engine with the vehicle model.

Open Example
