To Multimedia File
Write video frames and audio samples to multimedia file
Libraries:
Computer Vision Toolbox /
Sinks
Description
The To Multimedia File block writes video frames, audio samples, or both to
a multimedia file (.avi
, .wav
, .mj2
,
.mp4
, or .m4v
format).
You can compress the video frames or audio samples by selecting a compression algorithm. You can also control the type of video or audio in addition to other related properties the multimedia file receives.
If you have a Simulink® Coder™ license, you can generate a code from a model containing this block. To run a generated executable file, you may need to add precompiled shared library files to your system path. See Simulink Shared Library Dependencies, and Accelerating Simulink Models for details.
Note
This block supports code generation for platforms that have file I/O available. You cannot use this block with Simulink Desktop Real-Time™ software, because that product does not support file I/O.
This block performs best on platforms with Version 11 or later of Windows Media® Player software. This block supports only uncompressed RGB24 AVI files on Linux® and Mac platforms.
Examples
Read, Process, and Write Video Frames to File
Read video frames from a multimedia file, process them, and write them back to a new multimedia file.
Ports
Input
Image — Input image frame
matrix | array
Specify the input image frame as a matrix or an array. To write an intensity image frame to a multimedia file, specify it as an M-by-N matrix. For a color image frame, specify it as an M-by-N-by-3 array.
Dependencies
To enable this port:
Set the File type parameter to
AVI
,MJ-2000
,WMV
, orMPEG4
.If the File type parameter value is not
MJ-2000
, set the Write parameter toVideo and audio
orVideo only
.If the File type parameter value is
AVI
orMPEG4
, set the File color format parameter toRGB
.Set the Image signal parameter to
One multidimensional signal
.
Data Types: single
| double
| int8
| int16
| int32
| uint8
| uint16
| uint32
| Boolean
R — Red color component of image
matrix
Specify the red color component of the input image frame as an M-by-N matrix.
Dependencies
To enable this port:
Set the File type parameter to
AVI
,MJ-2000
,WMV
, orMPEG4
.If the File type parameter value is not
MJ-2000
, set the Write parameter toVideo and audio
orVideo only
.If the File type parameter value is
AVI
orMPEG4
, set the File color format parameter toRGB
.Set the Image signal parameter to
Separate color signals
.
Data Types: single
| double
| int8
| int16
| int32
| uint8
| uint16
| uint32
| Boolean
G — Green color component of image
matrix
Specify the green color component of the input image frame as an M-by-N matrix.
Dependencies
To enable this port:
Set the File type parameter to
AVI
,MJ-2000
,WMV
, orMPEG4
.If the File type parameter value is not
MJ-2000
, set the Write parameter toVideo and audio
orVideo only
.If the File type parameter value is
AVI
orMPEG4
, set the File color format parameter toRGB
.Set the Image signal parameter to
Separate color signals
.
Data Types: single
| double
| int8
| int16
| int32
| uint8
| uint16
| uint32
| Boolean
B — Blue color component of image
matrix
Specify the blue color component of the input image frame as an M-by-N matrix.
Dependencies
To enable this port:
Set the File type parameter to
AVI
,MJ-2000
,WMV
, orMPEG4
.If the File type parameter value is not
MJ-2000
, set the Write parameter toVideo and audio
orVideo only
.If the File type parameter value is
AVI
orMPEG4
, set the File color format parameter toRGB
.Set the Image signal parameter to
Separate color signals
.
Data Types: single
| double
| int8
| int16
| int32
| uint8
| uint16
| uint32
| Boolean
Y — Luma component of image
matrix
Specify the luma component of the input image frame as an M-by-N matrix.
Dependencies
To enable this port:
Set the File type parameter to
AVI
orMPEG4
.Set the Write parameter to
Video and audio
orVideo only
.Set the File color format parameter to
YCbCr 4:2:2
.
Data Types: single
| double
| int8
| int16
| int32
| uint8
| uint16
| uint32
| Boolean
Cb — Blue-difference chrominance component of image
matrix
Specify the blue-difference chrominance component of the input image as an M-by-N/2 matrix.
Dependencies
To enable this port:
Set the File type parameter to
AVI
orMPEG4
.Set the Write parameter to
Video and audio
orVideo only
.Set the File color format parameter to
YCbCr 4:2:2
.
Data Types: single
| double
| int8
| int16
| int32
| uint8
| uint16
| uint32
| Boolean
Cr — Red-difference chrominance component of image
matrix
Specify the red-difference chrominance component of the input image as an M-by-N/2 matrix.
Dependencies
To enable this port:
Set the File type parameter to
AVI
orMPEG4
.Set the Write parameter to
Video and audio
orVideo only
.Set the File color format parameter to
YCbCr 4:2:2
.
Data Types: single
| double
| int8
| int16
| int32
| uint8
| uint16
| uint32
| Boolean
Audio — Input audio signal
vector | matrix
Specify the input audio signal as a vector or a matrix. When specified as a matrix, the block treats each column as an independent channel.
Dependencies
To enable this port:
Set the File type parameter to
AVI
,WAV
,WMA
,MPEG4
,FLAC
, orOGG
.If the File type parameter value is
AVI
,WMV
, orMPEG4
set the Write parameter toVideo and audio
orAudio only
.
Data Types: single
| double
| int16
| int32
| uint8
Parameters
File name — Name of multimedia file
output.avi
(default) | character vector
Specify the name for the multimedia file the block writes. The block appends a file extension automatically based on the specified File type parameter. If the specified file name, including the file extension, already exists, the block overwrites the data in the existing file with the new input data.
By default, the block saves the file in the current working directory. To specify a different file location, click the Save As... button.
File type — Type of multimedia file
AVI
(default) | WAV
| MJ2000
| WMA
| WMV
| MPEG4
| FLAC
| OGG
Specify the type of multimedia file to write. The block supports the
AVI
, WAV
,
MJ2000
, WMA
,
WMV
, MPEG4
,
FLAC
, and OGG
file formats.
Write — Type of media
Video only
(default) | Audio only
| Video and audio
Specify the type of media to write. Depending on the value of the File
type parameter, you can select Video only
,
Audio only
, or Video and audio
.
Type of file | Supported type of media |
AVI |
|
WMV |
|
MPEG4 |
|
Dependencies
To enable this parameter, set the File type parameter to
AVI
, WMV
, or
MPEG4
.
Video compressor — Video compression algorithm
None (uncompressed)
(default) | DV Video Encoder
| MJPEG Compressor
| Lossy
| Lossless
Specify a video compression algorithm to reduce the size of the output file. The available options depend on the value of the File type parameter.
AVI
— Select either theDV Video Encoder
orMJPEG Compressor
algorithm. If you do not want to reduce the size of the file, selectNone (uncompressed)
.MJ2000
— Select either theLossy
orLossless
algorithm.
Note
The options for this parameter are the video compression algorithms installed on your system. For information about a specific video compressor, see the documentation for that compressor.
Dependencies
To enable this parameter, set the File type parameter to
MJ2000
or AVI
. For the
AVI
file type, set the Write
parameter to Video only
or Video and
audio
.
Compression Factor (>1) — Compression factor
10
(default) | integer greater than 1
Specify the compression factor as an integer greater than
1
.
Dependencies
To enable this parameter, set the File type parameter to
MJ2000
and the Video compressor
parameter to Lossy
.
Video Quality (0-100) — Quality of video
75
(default) | integer in range [0, 100]
Specify the quality of the video as an integer in the range [0, 100].
Dependencies
To enable this parameter, set the File type parameter to
MPEG4
and the Write parameter to
Video only
.
File color format — Color format of output video
RGB
(default) | YCbCr 4:2:2
Specify the color format of the video for the output file. The block supports the
RGB
and YCbCr 4:2:2
color
formats.
Dependencies
To enable this parameter, set the File type parameter to
AVI
or MPEG4
.
Image signal — Input port configuration for RGB video
One multidimensional signal
(default) | Separate color signals
Specify how the block accepts an RGB color video input. If you select
One multidimensional signal
, the block accepts input using
only the Image port. If you select Separate color
signals
, the block accepts an input video using three separate color
channels, divided across the R, G, and
B ports.
Dependencies
To enable this parameter:
Set the File type parameter to
AVI
,MJ-2000
,WMV
, orMPEG4
.Set the Write parameter to
Video and audio
orVideo only
.If the File type parameter value is
AVI
orMPEG4
, set the File color format parameter toRGB
.
Audio compressor — Audio compression algorithm
None (uncompressed)
(default) | CCITT A-Law
| CCITT u-Law
| GSM 6.10
| IMA ADPCM
| Microsoft ADPCM
| PCM
Specify an audio compression algorithm to reduce the size of the output file. The
block supports the CCITT A-Law
, CCITT
u-Law
, GSM 6.10
, IMA
ADPCM
, Microsoft ADPCM
, and
PCM
algorithms. If you do not want to reduce the size of
the file, select None (uncompressed)
.
Note
The options for this parameter are the audio compression algorithms installed on your system. For information about a specific audio compressor, see the documentation for that compressor.
Dependencies
To enable this parameter, use either of these options:
Set the File type parameter to
AVI
and set the Write parameter toVideo and audio
orAudio only
.Set the File type parameter to
WAV
.
Audio data type — Audio data type
Determine from input data type
(default) | 8-bit integer
| 16-bit integer
| 24-bit integer
| 32-bit integer
| 32-bit float
| 64-bit float
Specify the audio data type for the output file.
Dependencies
To enable this parameter select, use either of these options:
Set the File type parameter to
WAV
and the Audio compressor parameter toNone (uncompressed)
.Set the File type parameter to
FLAC
. This file type supports only the8-bit integer
,16-bit integer
, and24-bit integer
data types.
Block Characteristics
Extended Capabilities
C/C++ Code Generation
Generate C and C++ code using Simulink® Coder™.
Usage notes and limitations:
Host computer only. Excludes Simulink Desktop Real-Time code generation.
The executable generated from this block relies on prebuilt dynamic library files (
.dll
files) included with MATLAB®. Use thepackNGo
(Simulink Coder) function to package the code generated from this block and all the relevant files in a compressed ZIP file. Using this ZIP file, you can relocate, unpack, and rebuild your project in another development environment where MATLAB is not installed. For more details, see Code Generation, GPU, and Third-Party Support.
Version History
Introduced before R2006a
