predictObjectiveEvaluationTime
一連の点における目的関数の実行回数の予測
説明
例
最適化されたモデルにおける目的関数の評価回数の予測
この例では、最適化された SVM 分類用のベイズ モデルにおける目的関数の評価回数を推定する方法を示します。
最適化された SVM モデルを作成します。このモデルの詳細については、bayesopt を使用した交差検証分類器の最適化を参照してください。
rng default grnpop = mvnrnd([1,0],eye(2),10); redpop = mvnrnd([0,1],eye(2),10); redpts = zeros(100,2); grnpts = redpts; for i = 1:100 grnpts(i,:) = mvnrnd(grnpop(randi(10),:),eye(2)*0.02); redpts(i,:) = mvnrnd(redpop(randi(10),:),eye(2)*0.02); end cdata = [grnpts;redpts]; grp = ones(200,1); grp(101:200) = -1; c = cvpartition(200,'KFold',10); sigma = optimizableVariable('sigma',[1e-5,1e5],'Transform','log'); box = optimizableVariable('box',[1e-5,1e5],'Transform','log'); minfn = @(z)kfoldLoss(fitcsvm(cdata,grp,'CVPartition',c,... 'KernelFunction','rbf','BoxConstraint',z.box,... 'KernelScale',z.sigma)); results = bayesopt(minfn,[sigma,box],'IsObjectiveDeterministic',true,... 'AcquisitionFunctionName','expected-improvement-plus','Verbose',0);
さまざまな点における評価回数を予測します。
sigma = logspace(-5,5,11)'; box = 1e5*ones(size(sigma)); XTable = table(sigma,box); time = predictObjectiveEvaluationTime(results,XTable); [XTable,table(time)]
ans=11×3 table
sigma box time
______ _____ _______
1e-05 1e+05 0.25999
0.0001 1e+05 0.27678
0.001 1e+05 0.24152
0.01 1e+05 0.23432
0.1 1e+05 0.18991
1 1e+05 0.32159
10 1e+05 1.2852
100 1e+05 0.46865
1000 1e+05 0.17883
10000 1e+05 0.28235
1e+05 1e+05 0.23559
入力引数
results
— ベイズ最適化の結果
BayesianOptimization
オブジェクト
ベイズ最適化の結果。BayesianOptimization
オブジェクトを指定します。
XTable
— 予測点
列数が D のテーブル
予測点。列数が D のテーブルを指定します。D は、問題に含まれている変数の個数です。これらの点で予測が実行されます。
データ型: table
出力引数
バージョン履歴
R2016b で導入
