メモリの操作
R2025bメモリ操作ブロックはすべての Texas Instruments® C2000™マイクロコントローラーをサポートします。
ブロック
 | Memory Allocate | Allocate memory for new variable |
 | Memory Copy | Copy data from and to memory section |
 | Register Read/Write | Read from or write to various bit fields of TI C2000 Registers (R2024a 以降) |
モデル設定
注目の例
Serial Communication Using SCI Blocks
Use the SCI blocks to set up serial communication between the target hardware and your host computer for C2000™ Microcontroller Blockset.
Open-Loop Control of 3-Phase AC Motors Using C2000 Processors
Uses open-loop control (also known as scalar control or Volts/Hz control) to run a motor. This technique varies the stator voltage and frequency to control the rotor speed without using any feedback from the motor. You can use this technique to check the integrity of the hardware connections. A constant speed application of open-loop control uses a fixed-frequency motor power supply. An adjustable speed application of open-loop control needs a variable-frequency power supply to control the rotor speed. To ensure a constant stator magnetic flux, keep the supply voltage amplitude proportional to its frequency.
