Battery Pack Modeling
Simscape™ Battery™ includes MATLAB® objects and methods to automate the creation of Simscape battery models. These MATLAB objects allow you to define your own battery design specifications, visualize your battery in a 3-D space, customize the modeling resolution during simulation, and generate a Simulink® library that contains your custom generated battery blocks. You can use these blocks to assist with virtual battery design and verification, help develop battery control algorithms using Simulink, explore design sensitivities, and design thermal management strategies.
You can develop and test battery control strategies by simulating your custom battery blocks with the blocks in the Battery Management System (BMS) library of Simscape Battery. You can also thermally couple your custom battery models in Simulink with the blocks in the Thermal Management System library. Alternatively, you can define your own custom battery control and cooling system blocks.
|Define battery system and automatically generate dynamic models (Since R2023a)
|Create single electrochemical battery cell (Since R2022b)
|Create parallel assembly of battery cells (Since R2022b)
|Create module of battery parallel assemblies (Since R2022b)
|Create assembly of battery modules (Since R2022b)
|Create pack of module assemblies (Since R2022b)
|Set of conditional parameters for
Cell object (Since R2022b)
|Build custom library blocks from battery objects (Since R2022b)
|Modify properties of cells (Since R2023b)
|Modify properties of parallel assemblies (Since R2023b)
|Modify properties of modules (Since R2023b)
|Modify properties of module assemblies (Since R2023b)
|Modify properties of battery objects (Since R2023b)
|ParallelAssembly (Generated Block)
|Generated Simscape model of battery parallel assembly (Since R2022b)
|Module (Generated Block)
|Generated Simscape model of battery module (Since R2022b)
|ModuleAssembly (Generated Block)
|Generated Simscape model of battery module assembly (Since R2022b)
|Pack (Generated Block)
|Generated Simscape model of battery pack (Since R2022b)
- Battery Modeling Workflow
Learn how to create your battery models by using Simscape Battery.
- Manage Battery Run-Time Parameters with Centralized Script
Learn how to easily manage and characterize the run-time parameters of your battery models.
