Unpack net_ctrl Packet from FlightGear

Unpack net_ctrl variable packet received from FlightGear

  • Library:
  • Aerospace Blockset / Animation / Flight Simulator Interfaces

Description

The Unpack net_ctrl Packet from FlightGear block unpacks net_ctrl variable packets received from FlightGear via the Receive net_ctrl Packet from FlightGear block, and makes them available for the Simulink® environment.

Ports

Input

expand all

FlightGear packet to be unpacked, specified as an array.

Data Types: uint8

Output

expand all

Environment Outputs

Wind speed, specified as a scalar, in knots.

Dependencies

To enable this port, select the Show environment outputs check box.

Data Types: double

Wind direction, specified as a scalar, in deg.

Dependencies

To enable this port, select the Show environment outputs check box.

Data Types: double

Turbulence norm, specified as a scalar.

Dependencies

To enable this port, select the Show environment outputs check box.

Data Types: double

Ambient temperature, specified as a scalar, in deg C.

Dependencies

To enable this port, select the Show environment outputs check box.

Data Types: double

Ambient pressure, specified as a scalar, in inHg.

Dependencies

To enable this port, select the Show environment outputs check box.

Data Types: double

Ground elevation, specified as a scalar, in m.

Dependencies

To enable this port, select the Show environment outputs check box.

Data Types: double

Local magnetic variation, specified as a scalar.

Dependencies

To enable this port, select the Show environment outputs check box.

Data Types: double

Icing status, specified as a scalar, in deg.

Dependencies

To enable this port, select the Show environment outputs check box.

Data Types: uint32

Control Surface Position Inputs

Normalized aileron position [-1,1], specified as a scalar.

Dependencies

To enable this port, select the Show control surface position outputs check box.

Data Types: double

Normalized elevator position [-1,1], specified as a scalar.

Dependencies

To enable this port, select the Show control surface position outputs check box.

Data Types: double

Normalized rudder position [-1,1], specified as a scalar.

Dependencies

To enable this port, select the Show control surface position outputs check box.

Data Types: double

Normalized aileron trim position [-1,1], specified as a scalar.

Dependencies

To enable this port, select the Show control surface position outputs check box.

Data Types: double

Normalized elevator trim position [-1,1], specified as a scalar.

Dependencies

To enable this port, select the Show control surface position outputs check box.

Data Types: double

Normalized rudder trim position [-1,1], specified as a scalar.

Dependencies

To enable this port, select the Show control surface position outputs check box.

Data Types: double

Normalized flaps position [-0,1], specified as a scalar.

Dependencies

To enable this port, select the Show control surface position outputs check box.

Data Types: double

Normalized spoilers position [0,1], specified as a scalar.

Dependencies

To enable this port, select the Show control surface position outputs check box.

Data Types: single

Normalized speedbrake position [0,1], specified as a scalar.

Dependencies

To enable this port, select the Show control surface position outputs check box.

Data Types: single

Power for flaps, specified as a scalar. A value of 1 indicates that power is available.

Dependencies

To enable this port, select the Show control surface position outputs check box.

Data Types: uint32

Flap motor powered, specified as a scalar.

Dependencies

To enable this port, select the Show control surface position outputs check box.

Data Types: uint32

Engine/Fuel Outputs

Number of valid engines, specified as a scalar.

Dependencies

To enable this port, select the Show engine/fuel outputs check box.

Data Types: uint32

Master battery switch, specified as a vector.

Dependencies

To enable this port, select the Show engine/fuel outputs check box.

Data Types: uint32

Master alternator switch, specified as a vector.

Dependencies

To enable this port, select the Show engine/fuel outputs check box.

Data Types: uint32

Magnetos switch, specified as a scalar.

Dependencies

To enable this port, select the Show engine/fuel outputs check box.

Data Types: uint32

Power to starter motor, specified as a vector. A value of 1 indicates that power is available.

Dependencies

To enable this port, select the Show engine/fuel outputs check box.

Data Types: uint32

Normalized throttle position [0,1], specified as a vector.

Dependencies

To enable this port, select the Show engine/fuel outputs check box.

Data Types: double

Normalized mixture lever position [0,1], specified as a vector.

Dependencies

To enable this port, select the Show engine/fuel outputs check box.

Data Types: double

Normalized condition [0,1], specified as a vector.

Dependencies

To enable this port, select the Show engine/fuel outputs check box.

Data Types: uint32

Power to fuel pump, specified as a vector. A value of 1 indicates that pump is on.

Dependencies

To enable this port, select the Show engine/fuel outputs check box.

Data Types: uint32

Propeller advance [0,1], specified as a vector.

Dependencies

To enable this port, select the Show engine/fuel outputs check box.

Data Types: double

Feed tank to switch, specified as a vector.

Dependencies

To enable this port, select the Show engine/fuel outputs check box.

Data Types: uint32

Reverse switch, specified as a vector.

Dependencies

To enable this port, select the Show engine/fuel outputs check box.

Data Types: uint32

Engine status indicator, specified as a vector.

Dependencies

To enable this port, select the Show engine/fuel outputs check box.

Data Types: uint32

Left magneto status indicator, specified as a vector.

Dependencies

To enable this port, select the Show engine/fuel outputs check box.

Data Types: uint32

Right magneto status indicator, specified as a vector.

Dependencies

To enable this port, select the Show engine/fuel outputs check box.

Data Types: uint32

Spark plugs status indicator, specified as a vector. A value of 0 indicates that the plugs have failed.

Dependencies

To enable this port, select the Show engine/fuel outputs check box.

Data Types: uint32

Oil pressure status indicator, specified as a vector.

  • 0 — Normal oil pressure

  • 1 — Low oil pressure

  • 2 — Failed oil pressure

Dependencies

To enable this port, select the Show engine/fuel outputs check box.

Data Types: uint32

Fuel management status indicator, specified as a vector.

Dependencies

To enable this port, select the Show engine/fuel outputs check box.

Data Types: uint32

Number of valid tanks, specified as a scalar.

Dependencies

To enable this port, select the Show engine/fuel outputs check box.

Data Types: uint32

Fuel selector, specified as a vector.

  • 0 — Off

  • 1 — On

Dependencies

To enable this port, select the Show engine/fuel outputs check box.

Data Types: single

Specifies transfer from array value to tank, specified by value as a vector.

Dependencies

To enable this port, select the Show engine/fuel outputs check box.

Data Types: uint32

Cross feed valve, specified as a scalar.

  • 0 — False

  • 1 — On

Dependencies

To enable this port, select the Show engine/fuel outputs check box.

Data Types: single

Landing Gear Outputs

Left brake pedal position pilot, specified as a scalar.

Dependencies

To enable this port, select the Show landing gear outputs check box.

Data Types: double

Right brake pedal position pilot, specified as a scalar.

Dependencies

To enable this port, select the Show landing gear outputs check box.

Data Types: double

Left brake pedal position pilot, specified as a scalar.

Dependencies

To enable this port, select the Show landing gear outputs check box.

Data Types: double

Right brake pedal position pilot, specified as a scalar.

Dependencies

To enable this port, select the Show landing gear outputs check box.

Data Types: double

Brake parking position, specified as a scalar.

Dependencies

To enable this port, select the Show landing gear outputs check box.

Data Types: double

Gear handle position, specified as a scalar.

  • 0 — Gear handle up

  • 1 — Gear handle down

Dependencies

To enable this port, select the Show landing gear outputs check box.

Data Types: uint32

Avionic Outputs

Master avionics switch, specified as a scalar.

Dependencies

To enable this port, select the Show avionic outputs check box.

Data Types: uint32

Comm 1 frequency, specified as a scalar, in Hz.

Dependencies

To enable this port, select the Show avionic outputs check box.

Data Types: double

Comm 2 frequency, specified as a scalar, in Hz.

Dependencies

To enable this port, select the Show avionic outputs check box.

Data Types: double

Nav 1 frequency, specified as a scalar, in Hz.

Dependencies

To enable this port, select the Show avionic outputs check box.

Data Types: double

Nav 2 frequency, specified as a scalar, in Hz.

Dependencies

To enable this port, select the Show avionic outputs check box.

Data Types: double

Parameters

expand all

FlightGear software version, selected from the list.

Note

If you are using a FlightGear version older than 2.0, the model displays a notification from the Simulink Upgrade Advisor. Consider upgrading your FlightGear version using the Upgrade Advisor. For more information, see Supported FlightGear Versions.

Programmatic Use

Block Parameter: FlightGearVersion
Type: character vector
Values: scalar
Default: 'v2018.3'

Select this check box to include the control surface position outputs from the FlightGear net_ctrl data packet.

Dependencies

Select this check box to enable these input ports.

Signal Group 1: Control surface position outputs

NameUnitsTypeWidthDescription

aileron

1 (dimensionless)

double

1

Normalized aileron position [-1,1]

elevator

1 (dimensionless)

double

1

Normalized elevator position [-1,1]

rudder

1 (dimensionless)

double

1

Normalized rudder position [-1,1]

aileron_trim

1 (dimensionless)

double

1

Normalized aileron trim position [-1,1]

elevator_trim

1 (dimensionless)

double

1

Normalized elevator trim position [-1,1]

rudder_trim

1 (dimensionless)

double

1

Normalized rudder trim position [-1,1]

flaps

1 (dimensionless)

double

1

Normalized flaps position [-0,1]

spoilers

1 (dimensionless)

double

1

Normalized spoilers position [0,1]

speedbrake

1 (dimensionless)

double

1

Normalized speedbrake position [0,1]

flaps_power

1 (dimensionless)

uint32

1

Power for flaps (1 = power available)

flap_motor_ok

uint32

1

Flap motor powered

Programmatic Use

Block Parameter: ShowControlSurfacePositionOutputs
Type: character vector
Values: 'off' | 'on'
Default: 'off'

Select this check box to include the engine and fuel outputs from the FlightGear net_ctrl data packet.

Dependencies

Select this check box to enable these input ports.

Signal Group 2: Engine/fuel outputs

NameUnitsTypeWidthDescription

num_engines

uint32

1

Number of valid engines

master_bat

uint32

4

Master battery switch

master_alt

uint32

4

Master alternator switch

magnetos

uint32

4

Magnetos switch

starter_power

uint32

4

Power to starter motor (1 = starter power available)

throttle

1 (dimensionless)

double

4

Normalized throttle position [0,1]

mixture

1 (dimensionless)

double

4

Normalized mixture lever position [0,1]

condition

1 (dimensionless)

double

4

Normalized condition [0,1]

fuel_pump_power

uint32

4

Power to fuel pump 1 = on)

prop_advance

1 (dimensionless)

double

4

Propeller advance [0,1]

feed_tank_to

uint32

4

Feed tank to switch

reverse

uint32

4

Reverse switch

engine_ok

uint32

4

Engine status indicator

mag_left_ok

uint32

4

Left magneto status indicator

mag_right_ok

uint32

4

Right magneto status indicator

spark_plugs_ok

uint32

4

Spark plugs status indicator (0 = failed plugs)

oil_press_status

uint32

4

Oil pressure status indicator (0 = normal, 1 = low, 2 = full failure)

fuel_pump_ok

uint32

4

Fuel management status indicator

num_tanks

uint32

1

Number of valid tanks

fuel_selector

uint32

8

Fuel selector. (0 = off, 1 = on)

xfer_pump

uint32

5

Specifies transfer from array value to tank specified by value

cross_feed

uint32

1

Cross feed valve (0 = false, 1 = on)

Programmatic Use

Block Parameter: ShowEngineFuelOutputs
Type: character vector
Values: 'off' | 'on'
Default: 'off'

Select this check box to include the landing gear outputs from the FlightGear net_ctrl data packet.

Dependencies

Select this check box to enable these input ports.

Signal Group 3: Landing gear outputs

NameUnitsTypeWidthDescription

brake_left

double

1

Left brake pedal position pilot

brake_right

double

1

Right brake pedal position pilot

copilot_brake_left

double

1

Left brake pedal position copilot

copilot_brake_right

double

1

Right brake pedal position copilot

brake_parking

double

1

Brake parking position

gear_handle

uint32

1

Gear handle position (1 = gear handle down, 0 = gear handle up)

Programmatic Use

Block Parameter: ShowLandingGearOutputs
Type: character vector
Values: 'off' | 'on'
Default: 'off'

Select this check box to include the avionic outputs from the FlightGear net_ctrl data packet.

Dependencies

Select this check box to enable these input ports.

Signal Group 4: Avionics outputs

NameUnitsTypeWidthDescription

master_avionics

uint32

1

Master avionics switch

comm_1

Hz

double

1

Comm 1 frequency

comm_2

Hz

double

1

Comm 2 frequency

nav_1

Hz

double

1

Nav 1 frequency

nav_2

Hz

double

1

Nav 2 frequency

Programmatic Use

Block Parameter: ShowAvionicOutputs
Type: character vector
Values: 'off' | 'on'
Default: 'off'

Select this check box to include the environment outputs from the FlightGear net_ctrl data packet.

Dependencies

Select this check box to enable these input ports.

Signal Group 5: Environment outputs

NameUnitsTypeWidthDescription

wind_speed_kt

knot

double

1

Wind speed

wind_dir_deg

deg

double

1

Wind direction

turbulence_norm

double

1

Turbulence norm

temp_c

deg C

double

1

Ambient temperature

press_inhg

inHg

double

1

Ambient pressure

hground

m

double

1

Ground elevation

magvar

deg

double

1

Local magnetic variation

icing

uint32

1

Icing status

Programmatic Use

Block Parameter: ShowEnvironmentOutputs
Type: character vector
Values: 'off' | 'on'
Default: 'on'

Specify the sample time (-1 for inherited), as a scalar.

Programmatic Use

Block Parameter: SampleTime
Type: character vector
Values: scalar
Default: '1/30'

Introduced in R2012a
