IEEE 1588 Read Parameter
Output Precision Time Protocol status parameter values such as target computer system time, calendar time, and delays
Simulink Real-Time / IEEE 1588
The IEEE 1588 Read Parameter block reads the parameter that you select and send its value to the block output. The block label changes based on the parameter that you select.
You can use the IEEE 1588 Read Parameter block to read the target computer system time even without a PTPd process running.
Output — Output selected by Parameter to read parameter
The current parameter to read.
Parameter to read — Parameter to display at output
(nanosecond) (default) |
Calendar time (time_t) |
Offset from Master |
Master to Slave Delay |
One Way Delay
Specify the parameter to read. Select one of:
System time (nanosecond)— Current SLRT system time number of nanoseconds, counting from the current epoch. The output is a double.
Calendar time (time_t)— Current SLRT calendar time in
Offset from Master— Time offset in nanoseconds. The output is a double.
Master to Slave Delay— Time delay in nanoseconds. The output is a double.
One Way Delay— Time delay in nanoseconds. The output is a double.
