I2C
Inter-Integrated Circuit (I2C) は、2 線通信をサポートするチップ間インターフェイスです。I2C 周辺デバイスに接続し、そのデバイスとの間で読み取りと書き込みを行うことができます。Arduino® ボードは、I2C 通信プロトコルを使用してマイクロコントローラーや周辺装置 (センサーやディスプレイなど) と通信できます。
ブロック
トピック
- Support for I2C Communication
Set up and use I2C communication with Arduino hardware.
注目の例
Read Temperature from I2C-Based Sensor Using Arduino Hardware
Use Simulink® Support Package for Arduino® Hardware to configure and read temperature from an I2C based sensor.
Develop Gyroscope-Based Pedometer Using Arduino
How MATLAB® Function blocks are used in Simulink® models to implement algorithms using MATLAB functions. An Arduino® MKR1000 board is used to count the number of steps a person takes while walking. The pedometer is attached to the thigh of the person in such a way that the x-axis of the gyroscope is perpendicular to the direction of walking. The data from a gyroscope sensor is sent to an Android device using the User Datagram Protocol (UDP).
Estimate Orientation Using AHRS Filter and IMU Data in Simulink
Stream IMU data from sensors connected to Arduino® board and estimate orientation using AHRS filter and IMU sensor.
