Serial Port Interface

Communication using the serial port interface

Serial communication is the most common low-level protocol for communicating between two or more devices. Normally, one device is a computer, while the other device can be a modem, a printer, Arduino® hardware, another computer, or a scientific instrument such as an oscilloscope or a function generator. For many serial port applications, you can communicate with your instrument without detailed knowledge of how the serial port works. Communication through a serial port is established with a serialport object, which you create in the MATLAB® workspace. For information about creating a serialport object, see Create Serial Port Object.

Before you can write or read data, the serialport object and the instrument must have identical communication settings. For information, see Configure Serial Port Communication Settings.

Functions

expand all

serialportlistList of serial ports connected to your system (Since R2019b)
serialportConnection to serial port (Since R2019b)
configureTerminatorSet terminator for ASCII string communication with serial port (Since R2019b)
configureCallbackSet callback function and trigger condition for communication with serial port device (Since R2019b)
readRead data from serial port (Since R2019b)
readlineRead line of ASCII string data from serial port (Since R2019b)
readbinblockRead one binblock of data from serial port (Since R2019b)
writeWrite data to serial port (Since R2019b)
writelineWrite line of ASCII data to serial port (Since R2019b)
writebinblockWrite one binblock of data to serial port (Since R2019b)
writereadWrite command to serial port and read response (Since R2019b)
serialbreakSend break to device connected to serial port
flushClear serial port device buffers (Since R2019b)
getpinstatusGet serial pin status (Since R2019b)
setRTSSet serial RTS pin (Since R2019b)
setDTRSet serial DTR pin (Since R2019b)

Apps

Serial ExplorerCommunicate with devices connected to serial port (Since R2021b)

Blocks

Serial ConfigurationConfigure parameters for serial port
Serial Receive Receive binary data over serial port
Serial SendSend binary data over serial port

Topics

Troubleshooting

Troubleshooting Serial Port Interface

Troubleshoot the Serial Port interface.

Resolve Serial Port Connection Errors

Troubleshoot connecting to a serial port device.

Serialport Warning - Unable to Read All Data

Try these remedies when you receive some data, and you get the warning message: 'serialport' unable to read all requested data.

Serialport Warning - Unable to Read Any Data

Try these remedies when you receive no data, and you get the warning message: 'serialport' unable to read any data.
